Setting up your Hypercom T4230 or M4230

Step 1: Install the SIM module as shown below

Power off the terminal, turn the terminal over

and remove the SIM cover as shown.

Using your fingers, insert the SIM module into

the module carrier with the gold side facing the

terminal as shown. Push the SIM module in

until it stops.

Slide the metal carrier lock down and swing the

carrier into a vertical position as shown.

Swing the module carrier down until it touches

the connector, then slide the metal carrier lock

up to close it. Reinstall the SIM cover as

shown.

Table of Contents

Need help?

Do you have a question about the M4230 and is the answer not in the manual?

Page 1 Setting up your Hypercom T4230 or M4230 Step 1: Install the SIM module as shown below Power off the terminal, turn the terminal over Slide the metal carrier lock down and swing the and remove the SIM cover as shown.
Page 2 Step 2: Configure the Terminal These are the parameters that need to be set. Parameter Definition/Function GPRS Network Access The network name of the GPRS access provider Provider Name GPRS Network User Name The user name to access the service. GPRS Network Password The password used to access the service.
