Optimum T4100 - Download Instructions
T E R M I N A L
C O N F I G U R A T I O N
ACTION REQUIRED
1. Force terminal to Maintenance
menu screen by holding down
button and connecting to
FUNCTION
power supply
2. Select "1.Deployment Config"
3. Select "1.Terminal Config"
4. Select "1.Yes" (The terminal gets
an IP address assigned
automatically)
5. Select "1.Enable" if daylight
savings is observed
(Time adjusts automatically)
OR
Select "2.Disable" if daylight
savings is not observed
Application Manager version 1.3.10/20070123
TERMINAL DISPLAY
HYPERCOM Client Services – February 2007
ACTION REQUIRED
6. Key in current time
Press the hot-key next to AM or PM to
switch selection and press
ENTER
7. Select "1.Yes" to configure download
host
8. Select "1.Edit/View Host"
9. Key in TID (No check digit is needed)
Press
to confirm
ENTER
10. Select connection type
Select "2.IP/Ethernet" for IP download, follow step 11
OR
Select "1.Dial" for dial download, jump to step 18
TERMINAL DISPLAY
PAGE 1 of 3
