Raven ISO Product Controller II Operation Manual page 77

Code ID
.13
.14
523192
.15
.16
523193
.18
523520 .31
523906 .17
523907 .17
523908 .15
523909 .15
523910 .31
523911 .31
Troubleshooting: Diagnostic Trouble Code (DTC) List
Description
Sparge pressure transducer not
calibrated
New injection pump detected
Injection pump lost
communication
High system efficiency
Low system efficiency
Invalid flowmeter calibration
Equipment speed below the
speed range (single nozzle)
Equipment speed below the
speed range (multiple nozzles)
Equipment speed above the
speed range (single nozzle)
Equipment speed above the
speed range (multiple nozzles)
Nozzle power/temperature error
(single)
Nozzle power/temperature error
(multiple)
Recommended Actions
1. Refer to the "Tools Menu Settings Definitions"
on page 22 for assistance with pressure
transducer calibration.
1. A new injection pump was detected.
1. Verify the LED's on the injection pump are on.
2. Check the CAN connections of the injection
device.
3. Connect the Raven Service Tool to the
ISOBUS and verify communication.
1. Check the plumbing system for leaks.
2. Check the pressure transducer calibration.
3. Check the Flowmeter Calibration value.
4. Verify the fencerow outputs are not active.
5. Check the NCV's for debris or seal for wear.
1. Check the pressure transducer calibration.
2. Check the Flowmeter Calibration value.
3. Check the NCV's for debris or seal
deformation.
1. Enter a valid flowmeter calibration value.
1. Increase equipment speed to the range
displayed on the Hawkeye home screen. Refer
to the Hawkeye Upper Home Screen section
on page 44 and Hawkeye Lower Home
Screen section on page 47 for assistance with
the information provided on the home
screen.
1. Increase equipment speed to the range
displayed on the Hawkeye home screen.
1. Reduce equipment speed to the range
displayed on the Hawkeye home screen.
1. Reduce equipment speed to the range
displayed on the Hawkeye home screen. Refer
to the Hawkeye Upper Home Screen section
on page 44 and Hawkeye Lower Home
Screen section on page 47 for assistance with
the information provided on the home
screen.
1. Check for clogs in valve or associated
plumbing that may be preventing liquid flow
through the valve.
1. Check for restrictions in valves or associated
plumbing that may be preventing liquid flow
through the valve.
TROUBLESHOOTING
67
