AutoBoom™ Operator's Manual
PowerGlide Calibration

Advertisement

loading
Need help?

Need help?

Do you have a question about the PowerGlide AutoBoom and is the answer not in the manual?

Questions and answers

Related Manuals for Raven PowerGlide AutoBoom

Summary of Contents for Raven PowerGlide AutoBoom

  • Page 1 AutoBoom™ Operator’s Manual PowerGlide Calibration...
  • Page 3 H A P T E R N T RO D U C T I O N Congratulations on your purchase of the Raven PowerGlide Autoboom system! This system is designed to provide worry-free operation of your hydraulically controlled booms. Once set up, your system is very easy to use and requires almost no attention.

  • Page 4: Controller Description

    PowerGlide Autoboom Calibration and Operator’s Manual Controller Description • A) Main Power Switch - Turns power on and off • B) Display Screen • C) Function Keys • D) Power connection • E) Interface connection A) Main Power B) Display...
  • Page 5 Manual # 016-0130-061 Rev A 10/06 H A P T E R A L I B R A T I O N Calibrating a System Use this procedure if this is the first time you are calibrating the system. Important: Before beginning calibration, ensure that: •...
  • Page 6 PowerGlide Autoboom Calibration and Operator’s Manual 2. Power up the controller. A boot screen appears for about 5 seconds and then proceeds to the operators screen. Power Switch 3. Enable the left and right booms with the controller by pressing the middle button for the left boom and the far right button for the right boom.
  • Page 7 Manual # 016-0130-061 Rev A 10/06 5. If the booms did not start to rise, turn the adjustment knob clockwise until the booms begin to rise. If the booms did rise initially, go to step #6. Locking Ring Adjustment Knob 6.
  • Page 8 PowerGlide Autoboom Calibration and Operator’s Manual 8. The cartridge valve adjustment is now complete. Tighten the locking ring. Helpful Hint: On some systems, a second cartridge may be used to allow for individual adjustment of the left and right booms. For systems with two adjustment cartridges, repeat step 3 through 8 for the Left and Right boom cartridge.
  • Page 9 Y S T E M P E R A T I O N Operation of the PowerGlide Autoboom system is very simple. Assuming that the previous chapters’ instructions were followed and that the Autoboom is installed and operational, only a few basic operations are necessary for the system.
  • Page 10 PowerGlide Autoboom Calibration and Operator’s Manual Notes:...
  • Page 11 If too heavy, see question 2 on this page. 5. How do I disable Autoboom? Answer: Either activate the left and right boom up switches on the sprayer joystick to disable the PowerGlide Autoboom system or press the left and right disable function keys on the controller.

  • Page 15: Limited Warranty

    How Can I Get Service? Bring the defective part and proof of purchase to your Raven Dealer. If your Dealer agrees with the warranty claim, the Dealer will send the part and proof of purchase to their distributor or to Raven Industries for final approval.
  • Page 16 P.O. Box 5107 Fax: 605-331-0426 Sioux Falls, SD 57117-5107 www.ravenprecision.com atdinfo@ravenind.com Notice: This document and the information provided are the property of Raven Industries, Inc. and may only be used as authorized by Raven Industries, Inc. All rights reserved under copyright laws.
