C 6
HAPTER

TALLY REGISTER DEFINITIONS

®
The Raven Hawkeye system provides the following registers:
In addition to the area and volume tallies, the tally registers screen also displays the distance traveled and the
current volume per minute and area per hour.

TASK TALLIES

The task area and volume registers allow the operator to keep a running tally of product application in a specific
field or over a short duration of application such as a day or week.

LIFETIME TALLIES

The lifetime area and volume registers are intended to keep a running tally of a longer term of application data (i.e.
product application over a week, month, or season).

DEVICE STATS

The device area and volume statistics register keeps a running tally of the operating life of the Hawkeye
This tally cannot be reset by the machine operator.

DISTANCE

The distance register functions as a Hawkeye
time the distance register was cleared. The distance register display may also be helpful when fine tuning the
®
Hawkeye system or to assist with troubleshooting procedures.

FLOW RATE DISPLAY

During product application, the current volume of product applied per minute is displayed on the Totals Data tab.
This value may be helpful when fine tuning the Hawkeye

AREA/HOUR DISPLAY

The current area covered per hour is available on the Totals Data tab. This value may be helpful to check the
®
Hawkeye system calibration or to assist with troubleshooting procedures.
52
• Task • Lifetime
• Distance • Device
• Flow Rate • Area
®
system odometer and provides a distance traveled since the last
®
system or to assist with troubleshooting procedures.
ISO Product Controller II and Hawkeye Operation Manual
®
system.
