Raven ISO Product Controller II Operation Manual page 75

Code ID
.5
520593
.6
.2
523008
.31
523009 .2
.12
523088
.31
.12
523089
.31
Troubleshooting: Diagnostic Trouble Code (DTC) List
Description
NB HS current low multiple
NB HS current high multiple
Nozzle calibration tip mismatch/
error
No NCV tip size selected
Nozzle calibration spacing
mismatch/error
Nozzle memory error (single)
Nozzle memory warning (single)
Nozzle memory error (single
Nozzle memory warning
(multiple)
Recommended Actions
1. Reduce operating speed.
2. Verify the NCV voltage is above 10.5v.
3. Check the system cabling for damage.
4. Check the NCV duty cycle for proper
operation.
1. Contact a local Raven dealer if the issue is not
resolved.
1. Reduce operating speed.
2. Verify the NCV voltage is above 10.5v.
3. Check the system cabling for damage.
4. Check the NCV duty cycle for proper
operation.
1. Contact a local Raven dealer if the issue is not
resolved.
1. Select the appropriate tip type. Refer to the
Injection Pump Efficiency section on page 46
for additional assistance.
2. Restart the calibration wizard to reset the tip
type setting for the nozzle control system.
3. Cycle system power and reset defaults.
1. Enter a NCV tip size into the calibration
summary tab.
1. Restart the calibration wizard to re-enter the
tip spacing measurement.
2. Cycle system power.
3. Reset defaults.
1. Restart the calibration wizard.
2. Cycle system power.
3. Reset defaults.
4. Contact a local Raven dealer for additional
assistance.
1. Restart the calibration wizard.
2. Cycle system power.
3. Reset defaults.
4. Contact a local Raven dealer for additional
assistance.
1. Restart the calibration wizard.
2. Cycle system power and reset defaults.
3. Contact a local Raven dealer for additional
assistance.
1. Restart the calibration wizard.
2. Cycle system power.
3. Reset defaults.
4. Contact a local Raven dealer for additional
assistance.
TROUBLESHOOTING
65
