Raven ISO Product Controller II Operation Manual page 76

C 8
HAPTER
Code ID
523090 .1
523091 .1
523092 .31
523093 .31
523126 .13
.16
523136
.18
523137 .18
66
Description
Nozzle calibration error (single)
Nozzle calibration error
(multiple)
No tip information entered for
nozzle control valve (single)
No tip information entered for
nozzle control valves (multiple)
Unable to detect Hawkeye
Product Controller II ECU
orientation
Monitored flow rate is higher
than the target rate deadband
Monitored flow rate is lower than
the target rate deadband
Minimum flow not met
ISO Product Controller II and Hawkeye Operation Manual
Recommended Actions
1. Restart the calibration wizard to recalibrate
the nozzle control system.
2. Cycle system power.
3. Reset defaults.
1. Restart the calibration wizard to recalibrate
the nozzle control system.
2. Cycle system power.
3. Reset defaults.
1. Select the appropriate tip type. Refer to
Injection Pump Efficiency section on page 46
for additional assistance.
2. Restart the calibration wizard to reset the tip
type setting for the nozzle control system.
1. Restart the calibration wizard to configure tip
information for the Hawkeye
valves.
1. Check the Product Controller II ECU mounting
®
position and verify the Product Controller II
ECU is securely mounted.
2. Recalibrate the Product Controller II ECU gyro.
1. Reduce the equipment speed.
2. Review "Avoiding Skips with Hawkeye Nozzle
Control System" section on page 73.
3. Refer to the Hawkeye Upper Home Screen
section on page 44 for assistance with setting
or adjusting the target rate.
4. Refer to the System Settings Tab - Alarm
section on page 30 for assistance with setting
or adjusting the off rate percent.
1. Increase the equipment speed.
2. Refer to the Hawkeye Upper Home Screen
section on page 44 for assistance with setting
or adjusting the target rate.
3. Refer to the System Settings Tab - Alarm
section on page 30 for assistance with setting
or adjusting the off rate percent.
1. Activate product pump.
2. Review "Avoiding Skips with Hawkeye Nozzle
Control System" section on page 73.
3. Increase pump output to maintain the
minimum recommended flow rate for each
nozzle control valve.
®
nozzle control
