Chapter 2 Introduction - Raven ISO Product Controller II Operation Manual

CHAPTER
2
®
The Hawkeye Nozzle Control System is designed to provide PWM product rate and nozzle control via an ISOBUS
universal terminal (UT). Adding the Hawkeye
allow a machine operator to monitor and control product application rate and pressure independently directly
from the UT without additional displays, controllers, or consoles.
This document provides information regarding the following aspects of the Hawkeye
• Initial Setup and Navigation
• Calibration
®
• Hawkeye System Operation
®
• Hawkeye Operation When Used With Direct Injection
®
• Updating Hawkeye Components
NOTE: Prior to using the
Unit (Product Controller II ECU) must be calibrated for the control system. Refer to Chapter 3, System
Calibration, for assistance with completing the initial calibration wizard.
This manual assumes that the required control hardware is already installed on supported equipment
and is properly connected. Contact a local Raven dealer for additional information on supported
equipment configurations.
P/N 016-0171-584-H
I NTRODUCTION
C H A P T E R 2
®
control system to an existing ISOBUS product control system will
®
Hawkeye control features with any UT display, the
®
nozzle control system:
®
Hawkeye Electronic Control
