DISABLE NOZZLE CONTROL

®
The Hawkeye nozzle control system allows the operator to disable the nozzle control system during an
application to allow for the use of a secondary set of tips.
NOTE: When nozzle control is disabled, the
Be sure to open manual shut off valves on each nozzle body for the appropriate tip when
nozzle control features are disabled.
If Nozzle Control Valves are installed on the machine, the NCV's must be manually bypassed at the
boom or removed for the machine to operate properly when nozzle control is disabled. The system
will then operate as a conventional sprayer with the
NOTE: The nozzle control mode can only be changed outside of a job. To change modes in a field: close the
job, change the mode, and open the job again.
To disable nozzle control:
UT Menu
1. Open the UT Menu and select the Hawkeye
2. From the home screen, select the Tools Menu softkey along the right side of the display.
3. Select the Equipment Settings tab along the top of the display.
Select the Bypass option in the Nozzle Control Mode dropdown menu.

SYSTEM SETTINGS TAB - USER SETTINGS

To access the User Settings Menu:
UT Menu
Hawkeye Menu
1. Open the UT Menu and select the Hawkeye
2. From the home screen, select the Tools Menu softkey along the right side of the display.
3. Select the System Settings tab along the top of the display.
4. Select the User Settings button. The following settings may be viewed or modified:
• Display Smoothing
• External/RX Control
• Enable Turn Compensation
• Override Seconds
• NCV Performance
• Boom Recirculation
• Wireless Control Mode
Hawkeye® Nozzle Control and Sidekick Pro ICD Setup: Tools Menu Settings Definitions
HAWKEYE® NOZZLE CONTROL AND SIDEKICK PRO ICD SETUP
®
Hawkeye
Tools Menu
HawkeyeMenu
®
Menu button.
Tools Menu
®
Menu button.
• Auto Section Control
• PWM High Side Drive
• Calibrate Turn Compensation
• Enable Wireless Control
• Speed Cal
• Implement Switch
• Group End Nozzles
nozzle control valves will remain closed.
®
Hawkeye Product Controller II ECU.
Equipment
Settings
System
Settings
®
Hawkeye
User
Settings
User Settings
