Parameter Descriptions
VLT
4.10.6 13-5* States
13-51 SL Controller Event
Array [20]
Option: Function:
Select boolean input to define Smart Controller Event.
See 13-40 Logic Rule Boolean 1 for choices and
descriptions.
4 4
13-52 SL Controller Action
Array [20]
Option: Function:
Select action corresponding to SLC event.
Actions are executed when corresponding
event (13-51 SL Controller Event) is
evaluated as True.
[0] Disabled Function is disabled.
*
[1] No Action No action is taken.
[2] Select Set-up1 Changes active set-up to Set-up 1.
[3] Select Set-up2 Changes active set-up to Set-up 2.
[10] SelectPresetRef0 Selects preset reference 0
[11] SelectPresetRef1 Selects preset reference 1
[12] SelectPresetRef2 Selects preset reference 2
[13] SelectPresetRef3 Selects preset reference 3
[14] SelectPresetRef4 Selects preset reference 4
[15] SelectPresetRef5 Selects preset reference 5
[16] SelectPresetRef6 Selects preset reference 6
[17] SelectPresetRef7 Selects preset reference 7
[18] SelectRamp1 Selects ramp 1
[19] SelectRamp2 Selects ramp 2
[22] Run Issues start command to frequency
converter.
[23] RunReverse Issues start reverse command to
frequency converter.
[24] Stop Issues stop command to frequency
converter.
[25] Qstop Issues quick stop command to frequency
converter.
[26] DCstop Issues DC stop command to frequency
converter.
[27] Coast frequency converter coasts immediately.
All stop commands including coast
command stop the SLC.
[28] Freeze Output Freezes output frequency.
[29] StartTimer0 Starts timer 0.
[30] StartTimer1 Starts timer 1
[31] StartTimer2 Starts timer 2
[32] SetDO42Low Set Digital output 42 low.
[33] SetRelayLow Set Relay low.
[38] SetDO42High Set Digital output 42 high.
[39] SetRelayHigh Set Relay high.
[60] ResetCounterA Resets counter A to 0.
[61] ResetCounterB Resets counter B to 0.
44 MG02C602 - VLT
