Parameter Descriptions ®
VLT Micro Drive FC 51 Programming Guide
16-51 Pulse Reference
Range: Function:
0.0 % * [-200.0-200.0%] View actual pulse input converted to a
reference in percent.
16-52 Feedback
Range: Function:
0.000 * [-4999.000-4999.000] View analog or pulse feedback in
Hz.
4.13.4 16-6* Inputs and Outputs
16-60 Digital Input 18, 19, 27, 33
Range: Function:
0 [0-1111] View signal states from active digital inputs.
*
16-61 Digital Input 29
Range: Function:
0 [0-1] View signal state on digital input 29.
*
16-62 Analog Input 53 (volt)
Range: Function:
0.00 * [0.00-10.00 V] View input voltage on analog input
terminal.
16-63 Analog Input 53 (current)
Range: Function:
0.00 [0.00-20.00 mA] View input current on analog input
*
terminal.
16-64 Analog Input 60
Range: Function:
0.00 [0.00-20.00 mA] View actual value at input 60 either as
*
reference or protection value.
16-65 Analog Output 42 [mA]
Range: Function:
0.00 mA [0.00-20.00 mA] View output current on analog
*
output 42.
16-68 Pulse Input
Range: Function:
20 Hz [20-5000 Hz] View input frequency on pulse input
*
terminal.
16-71 Relay Output [bin]
Range: Function:
0 [0-1] View relay setting.
*
16-72 Counter A
Range: Function:
0 * [-32768-32767] View present value of Counter A.
16-73 Counter B
Range: Function:
0 [-32768-32767] View present value of Counter B.
*
®
MG02C602 - VLT is a registered Danfoss trademark
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx
4.13.5 16-8* FC Port
Parameter for viewing references from FC Port.
16-86 FC Port REF 1
Range: Function:
0 [0x8000-0x7FFF] View currently received reference from FC
*
Port.
4.13.6 16-9* Diagnosis Read-Outs
16-90 Alarm Word
Range: Function:
0 * [0-0xFFFFFFFF] Via alarm word sent via serial communi-
cation port in hex code.
16-92 Warning Word
Range: Function:
0 * [0-0xFFFFFFFF] View warning word sent via serial communi-
cation port in hex code.
16-94 Ext. Status Word
Range: Function:
0 [0-0xFFFFFFFF] View extended warning word sent via serial
*
communication port in hex code.
