5.1.9 4-** Limits/Warnings

Parameter
Parameter Description
Number
4-10 Motor Speed Direction
4-12 Motor Speed Low Limit [Hz]
4-14 Motor Speed High Limit [Hz]
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
4-40 Warning Frequency Low
4-41 Warning Frequency High
5 5
4-50 Warning Current Low
4-51 Warning Current High
4-54 Warning Reference Low
4-55 Warning Reference High
4-56 Warning Feedback Low
4-57 Warning Feedback High
4-58 Missing Motor Phase Function
4-61 Bypass Speed From [Hz]
4-63 Bypass Speed To [Hz]
Table 5.12

5.1.10 5-** Digital In/Out

Parameter
Parameter Description
Number
5-10 Terminal 18 Digital Input
5-11 Terminal 19 Digital Input
5-12 Terminal 27 Digital Input
5-13 Terminal 29 Digital Input
5-15 Terminal 33 Digital Input
5-34 On Delay, Terminal 42 Digital Output
5-35 Off Delay, Terminal 42 Digital Output
5-40 Function Relay
5-41 On Delay, Relay
5-42 Off Delay, Relay
5-55 Terminal 33 Low Frequency
5-56 Terminal 33 High Frequency
5-57 Terminal 33 Low Ref./Feedb. Value
5-58 Terminal 33 High Ref./Feedb. Value
Table 5.13
