Parameter Descriptions ®
VLT Micro Drive FC 51 Programming Guide
[28] Catch up Select Catch up/Slow down to increase or
reduce the resulting reference value by the
percentage set in 3-12 Catch Up/Slow Down
Value
[29] Slow down Same as Catch up [28]
[32] Pulse input Select Pulse input when using a pulse
(only terminal sequence as either reference or feedback.
33) Scaling is done in parameter group 5-5*
Pulse Input
[34] Ramp bit 0 Logic 0=Ramp1, see parameter group 3-4*
Ramp1
Logic 1=Ramp2, see parameter group 3-5*
Ramp2.
[60] Counter A Input for counter A.
(up)
[61] Counter A Input for counter A.
(down)
[62] Reset counter Input for reset of counter A.
A
[63] Counter B Input for counter B.
(up)
[64] Counter B Input for counter B.
(down)
[65] Reset counter Input for reset of counter B.
B
5-10 Terminal 18 Digital Input
Option: Function:
[8] * Start Select function from available digital input range.
See parameter group 5-1* Digital Inputs for choices.
5-11 Terminal 19 Digital Input
Option: Function:
[10] Reversing Select function from available digital input
*
range.
See parameter group 5-1* Digital Inputs for
choices.
5-12 Terminal 27 Digital Input
Option: Function:
[1] Reset Select function from available digital input range.
*
See parameter group 5-1* Digital Inputs* for choices.
5-13 Terminal 29 Digital Input
Option: Function:
[14] Jog Select function from available digital input range.
*
See parameter group 5-1* Digital Inputs for choices.
5-15 Terminal 33 Digital Input
Option: Function:
[16] Preset bit 0 Select function from available digital input
*
range.
See parameter group 5-1* Digital Inputs for
choices.
®
