Danfoss VLT Micro Drive FC 51 Programming Manual page 54

Parameter Lists ®
VLT Micro Drive FC 51 Programming Guide
8-9* Bus Jog / Feedback *[1] Approximately equals
8-94 Bus feedback 1 [2] Greater Than
0x8000-0x7FFF *0 13-12 Comparator Value
13-** Smart Logic -9999-9999 *0.0
13-0* SLC Settings 13-2* Timers
13-00 SL Controller Mode 13-20 SL Controller Timer
*[0] Off 0.0-3600 s *0.0 s
[1] On 13-4* Logic Rules
13-01 Start Event 13-40 Logic Rule Boolean 1
[0] False See par. 13-01 * [0] False
[1] True [30]-[32] SL Time-out 0-2
[2] Running 13-41 Logic Rule Operator 1
[3] InRange *[0] Disabled
[4] OnReference [1] And
[7] OutOfCurrentRange [2] Or
[8] BelowILow [3] And not
[9] AboveIHigh [4] Or not
[16] ThermalWarning [5] Not and
[17] MainOutOfRange [6] Not or
[18] Reversing [7] Not and not
[19] Warning [8] Not or not
[20] Alarm_Trip 13-42 Logic Rule Boolean 2
[21] Alarm_TripLock See par. 13-40
[22-25] Comparator 0-3 13-43 Logic Rule Operator 2
[26-29] LogicRule0-3 See par. 13-41 * [0] Disabled
[33] DigitalInput_18 13-44 Logic Rule Boolean 3
[34] DigitalInput_19 See par. 13-40
[35] DigitalInput_27 13-5* States
[36] DigitalInput_29 13-51 SL Controller Event
[38] DigitalInput_33 See par. 13-40
*[39] StartCommand 13-52 SL Controller Action
[40] DriveStopped *[0] Disabled
13-02 Stop Event [1] NoAction
See par. 13-01 * [40] DriveS- [2] SelectSetup1
topped [3] SelectSetup2
13-03 Reset SLC [10-17] SelectPresetRef0-7
*[0] Do not reset [18] SelectRamp1
[1] Reset SLC [19] SelectRamp2
13-1* Comparators [22] Run
13-10 Comparator Operand [23] RunReverse
*[0] Disabled [24] Stop
[1] Reference [25] Qstop
[2] Feedback [26] DCstop
[3] MotorSpeed [27] Coast
[4] MotorCurrent [28] FreezeOutput
[6] MotorPower [29] StartTimer0
[7] MotorVoltage [30] StartTimer1
[8] DCLinkVoltage [31] StartTimer2
[12] AnalogInput53 et Digital Output B High
[13] AnalogInput60 [32] Set Digital Output A Low
[18] PulseInput33 [33] Set Digital Output B Low
[20] AlarmNumber [38] Set Digital Output A High
[30] CounterA [39] Set Digital Output B High
[31] CounterB [60] ResetCounterA
13-11 Comparator Operator [61] ResetCounterB
[0] Less Than
Table 5.4
®
MG02C602 - VLT is a registered Danfoss trademark
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx
14-** Special Functions 15-41 Power Section
14-0*Inverter Switching 15-42 Voltage
14-01 Switching Frequency 15-43 Software Version
[0] 2 kHz 15-46 Frequency Converter
*[1] 4 kHz Order. No
[2] 8 kHz 15-48 LCP Id No
[4] 16 kHz not available for M5 15-51 Frequency Converter Serial
14-03 Overmodulation No
[0] Off 16-** Data Readouts
*[1] On 16-0* General Status
14-1* Mains monitoring 16-00 Control Word
14-12 Function at mains 0-0XFFFF
imbalance 16-01 Reference [Unit]
*[0] Trip -4999-4999
[1] Warning 16-02 Reference %
[2] Disabled -200.0-200.0 %
14-2* Trip Reset 16-03 Status Word
14-20 Reset Mode 0-0XFFFF
*[0] Manual reset 16-05 Main Actual Value [%]
[1-9] AutoReset 1-9 -200.0-200.0 %
[10] AutoReset 10 16-09 Custom Readout
[11] AutoReset 15 Dep. on par. 0-31, 0-32 and 4-14
[12] AutoReset 20 16-1* Motor Status
[13] Infinite auto reset 16-10 Power [kW]
[14] Reset at power up 16-11 Power [hp]
14-21 Automatic Restart Time 16-12 Motor Voltage [V]
0-600 s * 10 s 16-13 Frequency [Hz]
14-22 Operation Mode 16-14 Motor Current [A]
*[0] Normal Operation 16-15 Frequency [%]
[2] Initialisation 16-18 Motor Thermal [%]
14-26 Action At Inverter Fault 16-3* Drive Status
*[0] Trip 16-30 DC Link Voltage
[1] Warning 16-34 Heatsink Temp.
14-4* Energy Optimising 16-35 Inverter Thermal
14-41 AEO Minimum Magneti- 16-36 Inv.Nom. Current
sation 16-37 Inv. Max. Current
40-75% *66% 16-38 SL Controller State
15-** Drive Information 15-0* 16-5* Ref. / Feedb.
Operating Data 16-50 External Reference
15-00 Operating Days 16-51 Pulse Reference
15-01 Running Hours 16-52 Feedback [Unit]
15-02 kWh Counter 16-6* Inputs/Outputs
15-03 Power Ups 16-60 Digital Input 18,19,27,33
15-04 Over Temps 0-1111
15-05 Over Volts 16-61 Digital Input 29
15-06 Reset kWh Counter 0-1
*[0] Do not reset 16-62 Analog Input 53 (volt)
[1] Reset counter 16-63 Analog Input 53 (current)
15-07 Reset Running Hours 16-64 Analog Input 60
Counter 16-65 Analog Output 42
*[0] Do not reset [mA]16-68 Pulse Input [Hz]
[1] Reset counter 16-71 Relay Output [bin]
15-3* Fault Log 16-72 Counter A
15-30 Fault Log: Error Code 16-73 Counter B
15-4* Drive Identification 16-8* Fieldbus/FC Port
15-40 FC Type 16-86 FC Port REF 1
0x8000-0x7FFFF
