Parameter Lists

VLT
5 Parameter Lists
0-** Operation/Display 0-60 (Main) Menu Password
0-0/ Basic Settings 0-999 *0
0-03 Regional Settings 0-61 Access to Main/Quick Menu
*[0] International w/o Password
[1] US *[0] Full access
0-04 Oper. State at Power-up [1] LCP: Read Only
(Hand) [2] LCP: No Access
5 5
[0] Resume 1-** Load/Motor
[1] Forced stop, ref=f"old 1-0* General Settings
[2] Forced stop, re=0 1-00 Configuration Mode
0-1* Set-up Handling *[0] Speed open loop
0-10 Active Set-up [3] Process
*[1] Setup 1 1-01 Motor Control Principle
[2] Setup 2 [0] U/f
[9] Multi Setup
*[1] VVC plus
0-11 Edit Set-up 1-03 Torque Characteristics
*[1] Setup 1
*[0] Constant torque
[2] Setup 2
[2] Automatic Energy Optim.
[9] Active Setup 1-05 Local Mode Configuration
0-12 Link Setups
[0] Speed Open Loop
[0] Not Linked
*[2] As config in par. 1-00
*[20] Linked 1-2* Motor Data
0-31 Custom Readout Min Scale
1-20 Motor Power [kW] [HP]
0.00–9999.00
[1] 0.09 kW/0.12 HP
*0.00 [2] 0.12 kW/0.16 HP
0-32 Custom Readout Max Scale [3] 0.18 kW/0.25 HP
0.00–9999.00
[4] 0.25 kW/0.33 HP
*100.0 [5] 0.37 kW/0.50 HP
0-4* LCP Keypad [6] 0.55 kW/0.75 HP
0-40 [Hand on] Key on LCP
[7] 0.75 kW/1.00 HP
[0] Disabled [8] 1.10 kW/1.50 HP
*[1] Enabled [9] 1.50 kW/2.00 HP
0-41 [Off / Reset] Key on LCP
[10] 2.20 kW/3.00 HP
[0] Disable All [11] 3.00 kW/4.00 HP
*[1] Enable All [12] 3.70 kW/5.00 HP
[2] Enable Reset Only
[13] 4.00 kW/5.40 HP
0-42 [Auto on] Key on LCP [14] 5.50 kW/7.50 HP
[0] Disabled [15] 7.50 kW/10.00 HP
*[1] Enabled
[16] 11.00 kW/15.00 HP
0-5* Copy/Save
[17] 15.00 kW/20.00 HP
0-50 LCP Copy [18] 18.50 kW/25.00 HP
*[0] No copy
[19] 22.00 kW/29.50 HP
[1] All to LCP
[20] 30.00 kW/40.00 HP
[2] All from LCP 1-22 Motor Voltage
[3] Size indep. from LCP
50-999 V * 230-400 V
0-51 Set-up Copy
1-23 Motor Frequency
*[0] No copy 20-400 Hz *50 Hz
[1] Copy from setup 1 1-24 Motor Current
[2] Copy from setup 2
0.01-100.00 A *Motortype dep.
[9] Copy from Factory setup 1-25 Motor Nominal Speed
0-6* Password 100-9999 rpm * Motortype dep.
Table 5.1
50 MG02C602 - VLT
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx
®
Micro Drive FC 51 Programming Guide
Parameter Overview
1-29 Automatic Motor Tuning 1-82 Min Speed for Funct. at
(AMT) Stop [Hz]
*[0] Off 0.0-20.0 Hz *0.0 Hz
[2] EnableAMT 1-9* Motor Temperature
1-3* Adv. Motor Data 1-90 Motor Thermal Protection
1-30 Stator Resistance (Rs) *[0] No protection
[Ohm] * Dep. on motor data [1] Thermistor warning
1-33 Stator Leakage Reactance [2] Thermistor trip
(X1) [3] Etr warning
[Ohm] * Dep. on motor data [4] Etr trip
1-35 Main Reactance (Xh) 1-93 Thermistor Resource
[Ohm] * Dep. on motor data *[0] None
1-5* Load Indep. Setting [1] Analog input 53
1-50 Motor Magnetisation at 0 [6] Digital input 29
Speed 2-** Brakes
0-300% *100% 2-0* DC-Brake
1-52 Min Speed Norm. Magnet. 2-00 DC Hold Current
[Hz] 0-150% *50%
0.0-10.0 Hz *0.0 Hz 2-01 DC Brake Current
1-55 U/f Characteristic - U 0-150% *50%
0-999.9 V 2-02 DC Braking Time
1-56 U/f Characteristic - F 0.0-60.0 s *10.0 s
0-400 Hz 2-04 DC Brake Cut In Speed
1-6* Load Depen. Setting 0.0-400.0 Hz * 0.0 Hz
1-60 Low Speed Load Compen- 2-1* Brake Energy Funct.
sation 2-10 Brake Function
0-199% Load CompensationLoad *[0] Off
Compensation *100% [1] Resistor brake
1-61 High Speed Load Compen- [2] AC brake
sation 2-11 Brake Resistor (ohm)
0-199% *100% 5-5000 *5
1-62 Slip Compensation 2-16 AC Brake, Max current
-400-399% *100% 0-150% *100%
1-63 Slip Compensation Time 2-17 Over-voltage Control
Constant *[0] Disabled
0.05-5.00 s *0.10 s [1] Enabled (not at stop)
1-7* Start Adjustments [2] Enabled
1-71 Start Delay 2-2* Mechanical Brake
0.0-10.0 s * 0.0 s 2-20 Release Brake Current
1-72 Start Function 0.00-100.0 A *0.00 A
[0] DC hold/delay time 2-22 Activate Brake Speed [Hz]
[1] DC brake/delay time 0.0-400.0 Hz * 0.0 Hz
*[2] Coast/delay time 3-** Reference / Ramps
1-73 Flying Start 3-0* Reference Limits
*[0] Disabled 3-00 Reference Range
[1] Enabled *[0] Min to Max
1-8* Stop Adjustments [1] -Max to+Max
1-80 Function at Stop 3-02 Minimum Reference
*[0] Coast -4999-4999 *0.000
[1] DC hold 3-03 Maximum Reference
-4999-4999 *50.00
®
