Conversion Index; Change During Operation; 2-Set-Up; Type - Danfoss VLT Micro Drive FC 51 Programming Manual

Parameter Lists
VLT
16-9* Diagnosis Readouts 16-92 Warning Word
16-90 Alarm Word 0-0XFFFFFFFF
0-0XFFFFFFFF 16-94 Ext. Status Word
0-0XFFFFFFFF
Table 5.5

5.1.1 Conversion Index

The various attributes of each parameter are displayed in
the section Factory Settings. Parameter values are
5 5
transferred as whole numbers only. Conversion factors are
therefore used to transfer decimals according to Table 5.6.
Example:
Conversion index
2
1
0
-1
-2
-3
-4
-5
Table 5.6 Conversion Table

5.1.2 Change during operation

"TRUE" means that the parameter can be changed while
the frequency converter is in operation and "FALSE" means
that the frequency converter must be stopped before a
change can be made.

5.1.4 Type

Data Type Description
2 Integer 8
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9 Visible string
Table 5.7
54 MG02C602 - VLT
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx
®
Micro Drive FC 51 Programming Guide
18-** Extended Motor Data 18-81 Stator Leakage Reactance
18-8* Motor Resistors (High resolution)
18-80 Stator Resistance (High 0.000-99.990 ohm *0.000 ohm
resolution)
0.000-99.990 ohm *0.000 ohm
1-24 Motor Current has a conversion index of -2 (i.e.
conversion factor of 0.01 according to Table 5.6). To set the
parameter to 2.25 A, transfer the value 225 via Modbus.
The Conversion Factor of 0.01 means that the value
transferred is multiplied by 0.01 in the frequency converter.
The vale 225 transferred on the bus is thus perceived as
2.25 A in the frequency converter.
Conversion factor
10
100
1
0.1
0.01
0.001
0.0001
0.00001

5.1.3 2-Set-up

"All set-up": The parameter can be set individually in each
of the two set-ups, i.e. one single parameter can have two
different data values.
"1 set-up": Data value will be the same in both set-ups.
Type
Int8
Int16
Int32
Uint8
Uint16
Uint32
VisibleString
®
is a registered Danfoss trademark
