Parameter Lists ®
VLT Micro Drive FC 51 Programming Guide

5.1.7 2-** Brakes

Parameter
Parameter Description Default Value
Number
2-00 DC Hold Current 50%
2-01 DC Brake Current 50%
2-02 DC Braking Time 10 s
2-04 DC Brake Cut In Speed 0 Hz
2-10 Brake Function [0] Off
2-11 Brake Resistor (Ω)
2-16 AC Brake, Max current 100%
2-17 Over-voltage Control [0] Disabled
2-20 Release Brake Current 0 A
2-22 Activate Brake Speed [Hz] 0 Hz
Table 5.10

5.1.8 3-** Reference/Ramps

Parameter
Parameter Description Default Value
Number
3-00 Reference Range [0] Min to Max
3-02 Minimum Reference 0
3-03 Maximum Reference 50
3-10 Preset Reference 0%
3-11 Jog Speed [Hz] 5 Hz
3-12 Catch up/slow Down Value 0%
3-14 Preset Relative Reference 0%
3-15 Reference Resource 1 [1] Analog in 53
3-16 Reference Resource 2 [2] Analog in 60
3-17 Reference Resource 3 [11] Local bus reference
Relative Scaling Reference
3-18 Resource [0] No function
3-40 Ramp 1 Type [0] Linear
3-41 Ramp 1 Ramp up Time 3 s
3-42 Ramp 1 Ramp Down Time 3 s
3-50 Ramp 2 Type [0] Linear
3-51 Ramp 2 Ramp up Time 3 s
3-52 Ramp 2 Ramp down Time 3 s
3-80 Jog Ramp Time 3 s
3-81 Quick Stop Ramp Time 3 s
Table 5.11
®
MG02C602 - VLT is a registered Danfoss trademark
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx
Change During Conversi
2 Setup Type
Operation on Index
All set-ups TRUE 0 Uint16
All set-ups TRUE 0 Uint16
All set-ups TRUE -1 Uint16
All set-ups TRUE -1 Uint16
All set-ups TRUE - Uint8
All set-ups TRUE 0 Uint16
All set-ups TRUE 0 Uint16
5
All set-ups TRUE - Uint8
All set-ups TRUE -2 Uint32
All set-ups TRUE -1 Uint16
Change During Conversi
2 Setup Type
Operation on Index
All set-ups TRUE - Uint8
All set-ups TRUE -3 Int32
All set-ups TRUE -3 Int32
All set-ups TRUE -2 Int16
All set-ups TRUE -1 Uint16
All set-ups TRUE -2 Int16
All set-ups TRUE -2 Int16
All set-ups TRUE - Uint8
All set-ups TRUE - Uint8
All set-ups TRUE - Uint8
All set-ups TRUE - Uint8
All set-ups TRUE - Uint8
All set-ups TRUE -2 Uint32
All set-ups TRUE -2 Uint32
All set-ups TRUE - Uint8
All set-ups TRUE -2 Uint32
All set-ups TRUE -2 Uint32
All set-ups TRUE -2 Uint32
1 set-up TRUE -2 Uint32
57
5
