8-53 Start Select
Option: Function:
Select control of start function via digital
input and/or bus.
[0] Digital Input Activation via a digital input.
[1] Bus Activation via serial communication port.
[2] LogicAnd Activation via serial communication port and
a digital input.
[3] LogicOr Activation via serial communication port or a
*
digital input.
8-54 Reversing Select
Option: Function:
Select control of reversing function via digital
input and/or bus.
[0] Digital Input Activation via a digital input.
[1] Bus Activation via serial communication port.
[2] LogicAnd Activation via serial communication port and
a digital input.
[3] LogicOr Activation via serial communication port or a
*
digital input.
8-55 Set-up Select
Option: Function:
Select control of set-up selection via digital
input and/or bus.
[0] Digital Input Activation via a digital input.
[1] Bus Activation via serial communication port.
[2] LogicAnd Activation via serial communication port and
a digital input.
[3] LogicOr Activation via serial communication port or a
*
digital input.
8-56 Preset Reference Select
Option: Function:
Select control of Preset Reference selection
via digital input and/or bus.
[0] Digital Input Activation via a digital input.
[1] Bus Activation via serial communication port.
[2] LogicAnd Activation via serial communication port and
a digital input.
[3] LogicOr Activation via serial communication port or a
*
digital input.

4.9.6 8-8* Bus communication diagnostics

These parameters are used for monitoring the Bus
communication via the Port.
8-80 Bus Message Count
Range: Function:
0 N/A [0-0 N/A] This parameter shows the number of valid
*
telegrams detected on the bus.
®
MG02C602 - VLT is a registered Danfoss trademark
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx
8-81 Bus Error Count
Range: Function:
0 N/A * [0-0 N/A] This parameter shows the number of
telegrams with faults (e.g. CRC fault),
detected on the bus.
8-82 Slave Messages Rcvd
Range: Function:
0 N/A [0-0 N/A] This parameter shows the number of valid
*
telegrams addressed to the slave, sent by the
frequency converter.
8-83 Slave Error Count
Range: Function:
0 N/A [0-0 N/A] This parameter shows the number of error
*
telegrams, which could be executed by the
frequency converter.
4.9.7 8-9* Bus Feedback
Parameter for configuring bus feedback.
8-94 Bus Feedback 1
Range: Function:
0 [0x8000-0x7FFF] Bus feedback is delivered via FC or
*
Modbus by writing the feedback value into
this parameter.
