HDCP Authorized — This feature determines if a digital input reports as an HDCP
authorized sink to a source. Select this item to enable or disable HDCP communication
by selecting whether the IN1806 or IN1808 Series input reports to the source as an
authorized HDCP sink. Press
to toggle between
(default) and
On
For source devices that require encryption, enable HDCP Authorized. If HDCP
Authorized is disabled for sources that require encryption (for example, a Blu-ray player),
the output is muted or a warning message is displayed. Some source devices may
encrypt their output even if the source material does not require HDCP encryption,
preventing content from being displayed on a non-HDCP compliant display. Disable
HDCP Authorized to allow the output of the scaler to remain unencrypted.
NOTE: HDCP Authorized is permanently enabled on DisplayPort Input 1.
INn: EDID — Press the navigation buttons to select an EDID for the active input. Select
•
a discrete EDID from a list of factory-supplied EDID or select
output resolution and refresh rate. The
page lists the available EDID selections, including their SIS command variable numbers
(see the
Input EDID commands
Capture EDID — Select this item to capture the EDID of the sink device attached
•
to an output and save it to one of the 10 custom EDID slots. The IN1806 or IN1808
assigns the captured EDID to its selected input. To capture an EDID:
1.
Select
Capture EDID
displayed at the top of the OSD screen.
NOTES:
•
If no EDID has been captured yet, the names displayed for the slots are the
default:
1080p @ 60 Hz
•
If an EDID has been applied to a slot, last three letters of the EDID file
name (in parentheses) represent the name of the display manufacturer (for
example,
EXN
Select Slot to Capture 1A EDID: 1920x1200 @ 59.95 Hz (DEL)
C1:
C1:3840x2160 @ 59.95 Hz (DEL)
C2:
C2:1920x1080 @ 60 Hz (EXN)
C3:
C3:1920x1080 @ 60 Hz (EXN)
C4:
C4:1920x1080 @ 60 Hz (EXN)
C5:
C5:1920x1080 @ 60 Hz (EXN)
C6:
C5:1920x1080 @ 60 Hz (EXN)
C7:
C5:1920x1080 @ 60 Hz (EXN)
C8:
C5:1920x1080 @ 60 Hz (EXN)
C9:
C5:1920x1080 @ 60 Hz (EXN)
C10: C5:1920x1080 @ 60 Hz (EXN)
Figure 22.
Custom EDID Slots List Example
2.
Press the
or
save the current display EDID.
3.
Press the
ƒ
or
„
captured. In figure 22, output
IN1806 and IN1808 Series Scaling Presentation Switchers • Operation
to select this item, then press the
Enter
.
Off
Input EDID Resolutions table
on page 63 for information on the SIS commands).
, then press
. A list of the 10 custom EDID slots is
Enter
.
is an abbreviation of Extron).
button to move the highlighting to the slot to which you want to
button to display the output to which the select EDID will be
(HDMI) was selected and appears in the top panel.
1A
or
button
to use the current
Auto
on the next
34
