AC power connector — Connect a standard IEC power cord (provided) from a
A
100 to 240 VAC, 50-60 Hz power source to this connector (see
and
figures 4 through 6
DisplayPort input connector (input 1) — Connect a DisplayPort source to this
B
female DP connector (see
HDMI (with CEC) Loop Out connector — Connect a monitor to this buffered loop
C
out connector (see
figure 3
input via SIS (see
SIS Configuration and Control
the IN1806 and IN1808 Series Help File within the IN1806 and IN1808 module of PCS).
DTP2/XTP input connectors (inputs 7 and 8) — (IN1808 Series only) Connect
D
one or two DTP transmitters to the DTP2/XTP RJ-45 input connectors 7 and 8 (see
figures 4 through 6
on the previous page). These connectors also allow for remote
powering of DTP transmitters.
You can configure the TP inputs for DTP or XTP mode via SIS commands (see the
Twisted Pair Protocol commands
Submenu
on page 33), or PCS (see the IN1806 and IN1808 Series Help File within
the IN1806 and IN1808 module of PCS). For cable wiring and recommendations, see
Twisted Pair Recommendations for DTP, XTP, and HDBaseT Communication
page 22.
ATTENTION:
•
Do not connect these connectors to a computer or telecommunications
network.
•
Ne connectez pas ces ports à des données informatiques ou à un réseau de
télécommunications.
•
DTP2 remote power is intended for indoor use only. No part of the network that
uses DTP2 remote power should be routed outdoors.
•
L'alimentation DTP2 à distance est exclusivement réservée à un usage en
intérieur. Un réseau utilisant une alimentation à distance ne peut pas être routé
en extérieur.
The connectors for inputs 7 and 8 correspond to the following front panel LEDs:
Signal (Sig) LED — Lights when the scaler is receiving an active video signal from
•
a DTP2 transmitter or XTP matrix switcher.
Link LED — Lights when a valid link is established to a transmitter device.
•
HDMI (with CEC) output connector (output 1A) — Connect an HDMI or DVI (with
E
an appropriate adapter) output device to this HDMI output connector for HDMI video
with embedded audio (see
DTP2/XTP/HDBT output connector are mirrored, meaning that they display the same
image.
TIP:
Use Extron HDMI LockIt Lacing Brackets to secure HDMI cables to the device
HDMI Connections
(see
Consumer Electronics Control (CEC) — CEC control commands control basic
control functions such as power on and off, input switching, volume, and mute. The
IN1806 and IN1808 Series can issue CEC commands to a display device through the
HDMI and DTP2 ports.
IN1806 and IN1808 Series Scaling Presentation Switchers • Installation
on the previous page).
figure 3
and
figures 4 through
and
figures 4 through
6). This output can be tied to any
beginning on page 51) or PCS (see
on page 79), the on-screen display (see
figure 3
and
figures 4 through
on page 20).
figure 3
on page 12
6).
Input
on
6). This connector and the
14
