Additional Features of the IN1808 Series IPCP Models

Integrated IPCP Pro control processor — A built-in IPCP Pro 3355M control
•
processor enables complete AV system control.
• Energy efficient Class D stereo or mono amplifier: 2 x 50 watts @ 4 ohms,
2 x 25 watts @ 8 ohms, or 1 x 100 watts @ 70 volts — An Extron exclusive Class D
amplifier with Class D Ripple Suppression (CDRS), an Extron patented technology that
provides a smooth, clean audio waveform and high signal fidelity. CDRS eliminates
the high frequency switching ripple characteristic of Class D amplifiers, a source
of RF emissions which can interfere with sensitive AV equipment such as wireless
microphones.
• Support TouchLink Pro touchpanels, NPB Network Button Panels, and eBUS
button panels.
Integrated three-port AV LAN switch allows AV devices to be isolated from the
•
corporate network — Enable local control of AV devices connected to the AV LAN
switch while isolating the AV LAN network traffic from outside interference or intrusion.
AV LAN ports — Allow Extron devices on the AV LAN to receive firmware updates
•
and be remotely monitored, managed, and controlled through Extron GlobalViewer
Enterprise. AV LAN ports permit only communications from the Ethernet port for remote
management and firmware updates to Extron devices.
• Support secure industry standard communications protocols — Use industry
standard communication protocols, including HTTP (insecure), HTTPS, SSH, SFTP,
SMTP, NTP, Discovery Service, DHCP, DNS, ICMP, and IPv4.
• Two bidirectional RS-232 ports with software handshaking — Captive screw
serial ports can control two RS-232 devices.
• One bidirectional RS-232 port with hardware and software handshaking —
Captive screw serial port can communicate with one RS-232 serially controlled device.
• Two IR/Serial ports for one-way control of external devices.
• Four Digital I/O ports — Allows for interfacing with other systems in the room.
Four relays for controlling room functions — Enable control of lighting, screen
•
settings, and other device functions.
eBUS port for connecting eBUS button panels and accessories.
•
• Ethernet monitoring and control on each Ethernet port — Manage, monitor, and
control AV devices using a standard Ethernet network.
DHCP server for AV LAN — Automatically distributes IP addresses and network
•
configuration parameters for AV devices connected to the local AV LAN, which
streamlines system setup and management.
Support Building Management System (BMS) protocols such as BACnet, KNX,
•
and DALI — These protocols allow for centralized monitoring and control of mechanical
and electrical systems that include HVAC, lighting, power, fire, and security.
• Support LinkLicense — Extron LinkLicense unlocks features that add convenience,
expand system functionality, and enhance the capabilities of Extron products.
Support 10/100/1000Base-T.
•
• Support Ethernet-controllable devices — Allow for control of multiple Ethernet
enabled AV devices such as displays, switchers, and sources.
Automatic clock synchronization allows touchpanel to display the accurate
•
time and date.
Support control system synchronization — Synchronization allows users to retain
•
and recover the state of their configured endpoints in case of network or power failure.
