▶1st Gear (3.932)
16. Torque converter lockup clutch
A. Engine speed
B. Transmission, input shaft
C. 1st gear ratio
D. 2nd gear ratio
-
Input shaft: Clockwise rotation
- Front sun gear: Locked by F1 and B1, Planetary gear carrier: Rotation with reduced speed
- Rear ring gear: Counterclockwise rotation
-
Rear sun gear: Locked by F2 and B2, Planetary gear carrier: Clockwise rotation with reducedspeed
Center ring gear: Clockwise rotation
- Center sun gear: Locked by B2, Rotation with reduced speed
- Output shaft: Clockwise rotation
-
Gear C1 C2
1
E. 3rd gear ratio
F. Mounting elements
H. Rear planetary gear set
L. Stator
C3 B1 B2
● ● ●
3) 3)
3650-01
M. Center planetary gear set
P. Impeller
T. Turbine wheel
V. Front planetary gear set
B3 F1 F2
● ●
01-13
3) Overrun
Lockup clutch
