Component
Hot water inlet pipe
Alternator
A/C compressor
A/C bracket
Intake manifold
Oil filter module
Knock sensor
Cam position sensor
T-MAP pressure
sensor
Exhaust manifold
Turbocharger
T/C support bolt
T/C support nut
T/C oil supply pipe
T/C oil return pipe
EGR valve
EGR pipe bolt
(Intake side)
EGR pipe bolt
(EGR cooler side)
Idle pulley/Tensioner
pulley
Bolt
Size
Quantity
M6×12
2
M10×90
1
M10×116
1
M8×85
4
M6×25
4
M8×35
2
M8×110
6
M8×40
6
M8×20
1
M8×140
2
M8×28
2
M8×14
1
M6×20
1
M8 10
M8 3
1
M8 1
M6(block side) 1
M6(turbo side) 1
M6×16
2
(turbo side)
M6×16
2
(block side)
M8×22
3
M8×16
2
M8×16
2
1
0000-00
Specified torque
(Nm)
(Total torque)
10±1Nm
(lower) 25±2.5Nm
(upper) 46±4.6Nm
25±2.5Nm
10±1Nm
25±2.5Nm
25±2.5Nm
25±2.5Nm
25±2.5Nm
25±2.5Nm
20±5Nm
10~14Nm
10±1Nm
40±4Nm
25±2.5Nm
25±2.5Nm
25±2.5Nm
10±1.0Nm
17±2.0Nm
10±1Nm
10±1Nm
25±2.5Nm
10±1.0Nm
25±2.5Nm
45±4.5Nm
