1B2-16 M161 ENGINE MECHANICAL
Preceding Work: Removal of cooling fan
1 Poly V-Belt (2,155 mm)
2 Belt Tensioning Pulley
POLY V - BELT
3 Belt Tensioner
Removal & Installation Procedure
1. Release the belt tension by turning the stud on
the cap with 12 sided wrench or spanner
counterclock-wise.
2. Remove the poly v-belt.
Notice: Check the belt for damage and tensioning
pulley bearing point for wear and replace them if
necessary.
3. Install the belt after prying the tensioning pulley.
YAD1A130
YAD1B5P0
