Opening the gripper manually

7.3 Opening the gripper manually
1 On/off switch
￭￭￭￭￭￭￭￭
54
NOTICE
Additional information on the controls, see OMNIS Sample Robot –
Indicators and controls (see chapter 3.6, page 32).
CAUTION
Unsecured sample beakers
If the gripper is opened, then unsecured sample beakers can cause
injuries and property damage to the instrument.
Wear personal protective equipment.
￭
Always hold the sample beaker in one hand when the gripper is
￭
being opened manually.
Figure 29 Main module Pick&Place, front
Opening the gripper manually
Prerequisites:
The sample robot stands still.
￭
1 Hold the sample beaker in one hand.
2 LED
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
