2 Inserting the electrode
Insert the electrode from above into the position intended for this
purpose.
3 Mounting the aspiration tubing
Insert the aspiration tip from above into the position intended for this
purpose and mount the aspiration tubing.
If necessary, shorten the aspiration tip to the desired length after-
wards.
4 Mounting the dosing tubing
Mount the dosing tubing onto the preinstalled dosing tips.
5 Inserting the rod stirrer
Insert the rod stirrer from above into the position intended for this
purpose, place the corresponding stirring propeller from below onto
the rod stirrer coupling and connect the cable of the rod stirrer to the
MDL socket of the main module.
NOTICE
This step is not necessary if the Pick&Place module involved is
the version with the built-in magnetic stirrer (2.1014.0110).
