Main module – Connectors
1
Human Interactive Device (HID)
3
Metrohm Device Link (MDL)
NOTICE
Symbol labeling
Observe the connector symbols when connecting the instruments.
Figure 18
Connectors – Main module Pick&Place
2
Local Area Network (LAN)
4
Power socket
Functional description
￭￭￭￭￭￭￭￭
