Mounting the safety shield

5.5 Mounting the safety shield
1 Safety shield
3 Markings "LOCK" and "UNLOCK"
￭￭￭￭￭￭￭￭
44
WARNING
Working without a safety shield
A risk of injury exists when working without a safety shield mounted.
Never operate the sample robot without a safety shield.
￭
Before beginning work, make sure that all of the protective devi-
￭
ces are mounted on the sample robot and operational.
Always wear personal protective equipment when working with
￭
the sample robot.
NOTICE
The safety shield has the designations "LOCK" for closed and
"UNLOCK" for open.
Figure 25 Inserting the safety shield
2 Titration head holder
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
