Keysight InfiniiVision 4000 X-Series Oscilloscopes
Programmer's Guide
23 :MARKer Commands
Set and query the settings of X-axis markers (X1 and X2 cursors) and the Y-axis
markers (Y1 and Y2 cursors). See
page 529.
Table 109 :MARKer Commands Summary
Command
n/a
:MARKer:MODE <mode>
page 531)
(see
:MARKer:X1:DISPlay
{{0 | OFF} | {1 |
page 532)
ON}} (see
:MARKer:X1Position
<position>[suffix]
page 533)
(see
:MARKer:X1Y1source
<source> (see
page 534)
:MARKer:X2:DISPlay
{{0 | OFF} | {1 |
page 535)
ON}} (see
Query
:MARKer:DYDX? (see
page 530)
:MARKer:MODE? (see
page 531)
:MARKer:X1:DISPlay?
page 532)
(see
:MARKer:X1Position?
page 533)
(see
:MARKer:X1Y1source?
page 534)
(see
:MARKer:X2:DISPlay?
page 535)
(see
"Introduction to :MARKer Commands"
Options and Query Returns
<return_value> ::= •Y/•X value in
NR3 format
<mode> ::= {OFF | MEASurement |
MANual | WAVeform | BINary | HEX}
<setting> ::= {0 | 1}
<position> ::= X1 cursor position
value in NR3 format
[suffix] ::= {s | ms | us | ns |
ps | Hz | kHz | MHz}
<return_value> ::= X1 cursor
position value in NR3 format
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= <source>
<setting> ::= {0 | 1}
on
