Command Differences From 3000 X-Series Oscilloscopes

The Keysight InfiniiVision 4000 X-Series oscilloscopes command set is most
closely related to the InfiniiVision 3000 X-Series oscilloscopes (and the
7000A/B Series, 6000 Series, and 54620/54640 Series oscilloscopes before them).
The main differences between the version 3.00 programming command set for the
InfiniiVision 4000 X-Series oscilloscopes and the 2.10 programming command set
for the InfiniiVision 3000 X-Series oscilloscopes are related to:
• Zone qualified trigger feature.
• USB 2.0 triggering and serial decode options (which replace the old
• Two-channel built-in waveform generator (with Option WGN license) instead of
• Support for modulation of the waveform generator output on WaveGen1.
• A couple new built-in demo signals (with the education kit).
• Four reference waveforms (instead of two).
• Four math functions (instead of g(t) and f(t)).
• Touchscreen, sidebar, and display related command additions.
• Measure cursors mode.
• Support for controlling the digital voltmeter analysis feature.
• Power measurements application modifications.
More detailed descriptions of the new, changed, obsolete, and discontinued
commands appear below.
New Commands
Command
:ACQuire:RSIGnal (see
page
:DISPlay:MENU (see
page
:DISPlay:SIDebar (see
page
:DVM Commands (see
page
:FUNCtion<m>:AVERage:COUN
t (see
:MEASure:CPLoss (see
page
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
:TRIGger:USB commands).
one channel.
310)
420)
423)
427)
page 462)
648)
Description
Lets you select the 10 MHz reference signal mode.
Changes the front panel softkey menu.
Specifies the sidebar dialog to display on the screen.
Commands for controlling the digital voltmeter analysis feature.
Specifies the count for the Averaged Value math function.
Installs a power loss per cycle measurement on screen or returns
the measured value.
