Measuring Strips - X-Rite 890 Operation Manual

It is important to make sure control strips and reference strips used are from
the same batch number.
Always inspect control strips for damage before measuring. Care must also
be taken when handing strips. Fingerprints on measurable patches can affect
density values.
IMPORTANT! When inserting strips into the instrument, there should be at
least a 30.5mm (1.25") leader before the outside edge of the first measurable
target or the first target may not be detected. For information on measuring
leaderless strips (30.5mm), refer to your Control Strip and Balance Print
Format Guide, Section Five.
Section Four Contents
•

Measuring Strips

•
Manually Transmitting Strip Data
MEASURING STRIPS
Refer to your Control Strip and Balance Print Format Guide to located your
control strip for proper insertion direction.
1. Select strip channel from Main Menu page 1.
MAIN MENU
p1
2. If format displayed is not correct, press key llll (other) to select correct
strip format.
READ
AT < 18 18 > other
Strip Operation
pap film bal
k:RA—4 ALL
S E C T I O N F O U R
4-1
