S E C T I O N T W O

AUTO CALIBRATION PROCEDURE

NOTE: Make sure the Auto-Cal strip is free of dust, dirt, and smudgemarks.
Refer to Section Eight for cleaning procedure. Handle cal strip by the edges.
1. Press key lll (cal) located on Function Menu page (p3) to initiate calibration.
•
•
Auto must be
displayed in upper-
case. If not, press
key l to toggle on.
2. Insert the designated end of the Auto-Cal strip into the 35mm slot until it
35mm slot
•
NOTE: If
when a cal strip is measured, the strip may be dirty—refer to Section Eight
for procedure. However, if cleaning the strip does not resolve the problem,
enter calibration manually then re-measure the strip.
2-2
FUNCTION MENU
p3 cnfg cal load
The instrument screen momentarily displays
TRANSMISSION during automatic transmission calibration
(reading air), and
CALIBRATING MOTOR SPEED.
CALIBRATING
TRANSMISSION
After this is complete, the instrument screen asks you to
STRIP . Make sure the key labeled AUTO is upper-case lettering. If not,
press key l (AUTO) to toggle to upper-case. Note, lower-case lettering
denotes manual calibration (MANUAL) is activated.
INSERT CAL STRIP
manual
AUTO
comes to rest against the drive rollers.
X-RITE Auto-Cal Strip P/N 880-100 Patent Pending
INSERT THIS END
Note insertion direction
READING is momentarily displayed on the screen followed by
calibration density values. Auto calibration is now complete and the
instrument screen returns to the Main menu.
UNRECOGNIZEABLE STRIP
CALIBRATING
CALIBRATING
MOTOR SPEED...
INSERT CAL
SERIAL #: XXX-XXX
CAL R= 0.04 G= 0.07 B= 0.08
momentarily appears on the screen
