X-Rite 890 Operation Manual page 39

Technical Specifications
Transmission Process Control
Film Width
Measurement Speed
Spectral Response
Density Range
Density Accuracy
Density Repeatability
Control Strip Measurement Area 0.375" (length) x 0.5" (wide) minimum
Reflection (paper) Process Control and Printer Balance
Paper Width
Measurement Speed
Control Strip Measurement Area 0.375" L x 0.5" W minimum
Printer Balance Measuring Area
Spectral Response
Density Range
Density Accuracy
Density Repeatability
General Specifications
AC Adapter
Instrument Dimensions
Specifications and design subject to change without notice.
A P P E N D I X A
35mm fixed slot or 1.4–6.0in. adjustable
1.1 to 1.4 in./sec. (1.2 in./sec. typical)
Status M
0–4.0D
±.02D (0–3.0D), ±1% (3.1–3.4D)
±3% (3.5–4.0D)
±.01D (0–3.0D)
1.4–6.0in. adjustable slot
1.3in./sec.
0.75" diameter minimum
Status A
0–2.5D
±.02D
±.01D
12VDC @ 0.7amp
115VAC (P/N SE30-61)
230VAC (P/N SE30-62)
7.2" W x 6.0" D x 2.75" H
(182.8mm W x 152.4mm D x 69.mm H)
A-1
