View Strip Data

Control strip data consists of the "actual" values measured by the instrument.
Control strip data is viewed after a strip measurement or by selection from
the Main Menu (p2).
Viewing Data after Control Strip Measurement
1. Press key l (Stain) to page through RGB data fields of the strip.
2. After viewing data, press key llll (exit) to exit.
Red Green Blue
0.29 0.34 0.54
Stain
Viewing Control Strip Data from View Menu
1. Press key ll (view) located on Function Menu page (p2) to enter View
Menu screen.
FUNCTION MENU
p2 view xmit
2. Press key ll (pap), key lll (film), or key llll (bal) to select strip category.
VIEW MENU
pap film
3. Press key ll or key lll (Stain) to page through RGB data fields of the
strip. After viewing data, press key llll (exit) to exit to the View Menu, or
simultaneously press key lll and key llll (MENU) to exit to the Main
Menu.
Red Green Blue
0.29 0.34 0.54
VIEW > Stain
NOTE:
CHANNEL IS EMPTY
is available to view.
S T R I P O P E R A T I O N
exit
bal
exit
appears in the display if no control strip data
