Setting System Configuration
The system configuration allows you to customize your instrument to meet
your requirements. The configuration should be viewed and edited as needed
before any measurements are taken.
Section Three Contents
•

Instrument Configuration

INSTRUMENT CONFIGURATION
The configuration functions are contained in two main screen pages. Page
one contains setup functions for instrument beeper tone, and network. Page 2
is broken down into five menu pages, four of which are submenus—p2a,
p2b, and so on. Page two menus contain serial interface control options.
Descriptions for all configuration options are listed below, followed by set up
procedures.
Page 1 Configuration Options
TONE
Use to adjust the instruments beeper volume. Available settings are: OFF,
SOFT, and LOUD.
NET (Networking)
Enables the instrument to automatically send and receive data via the modem
at a predetermined time that is selected by the QC computer. Available
settings are: OFF, OUT, IN, and I&O.
•
OFF - disables the instrument from automatically sending or receiving data.
•
OUT - enables unit to call out via modem from QC host.
•
IN - enables unit to answer incoming call on modem from QC host.
•
I&O - enables both automatic transmission and reception of data.
S E C T I O N T H R E E
3-1
