Applying Power - X-Rite 890 Operation Manual

APPLYING POWER

To apply power to the instrument:
1. Verify that the voltage indicated on the adapter complies with the AC
line voltage in your area. If not, contact X-Rite or your authorized
representative.
2. Insert the small plug from the adapter into the power-input connector on
the instrument.
3. Plug the detachable line cord into the adapter.
4. Plug the line cord into an AC wall receptacle.
IMPORTANT: To extend the life of the internal memory battery, it is
recommended that the instrument remain plugged into AC power. If you are
using a modem, AC power must be applied in order to transmit or receive data.
Power Input
At initial power-up, the instrument performs a "boot memory test." The
testing sequence is displayed on the instrument screen. If all internal tests are
OK, Page 1 Main Menu displays—see next page.
Testing Program
boot memory...3
XRite 890
Copyrt 1989—1997
Detachable Line Cord
Adapter
2
1
vXXXX
G E T T I N G S T A R T E D
1-3
