S E C T I O N O N E

USER INTERFACE

The 890 instrument incorporates a three page menu system. Menu pages are
displayed by continually pressing keyswitch l (p#) on the instrument. The
first page contains all the predefined control strips. The last two pages
provide access to the instrument setup options and strip measurement data.
Main Menu
•
•
•
Function Menus
•
•
•
•
•
1-4
pap (paper) - accesses the paper measurement channel. The format
selected remains selected until changed.
film - access the film measurement channel. The format selected remains
selected until changed.
bal (printer balance) - accesses the printer balance measurement channel.
The format selected remains selected until changed.
view - used to view data of the last strip measured.
xmit (transmit)- used to manually transmit data of the last strip
measured—via RS-232 port.
cal (calibration) - used for calibration.
cnfg (configuration) - used to access system configuration options.
load - for updating the instrument's firmware (see Appendix E).
MAIN MENU
p1 pap film bal
FUNCTION MENU
p2 view xmit
FUNCTION MENU
p3 cnfg cal load
