S E C T I O N O N E

Film Strip

The Film category requires that the film strip be inserted into the 35mm slot
located above the center diamond. In this example—Kodak C41—the strip
can be inserted in either direction. Refer to your Control Strip and Balance
Print Format Guide for information on all strips supported.
Indicates ALL patches are measured

Printer Balance Strip

The Printer Balance category in the instrument has five basic strip formats:
Wht-Eye, Blk-Eye, No-Ring, K:3510, and Small-BE. Each category has six
print options to choose from. Refer to your Printer Balance and Control
Guide for detailed information on all aspects of the printer balance strips.
Due to the amount of variation between printer balance strips, no guide
setting numbers appear in the display.
In this example—Blk-Eye, UNO 1-Pass—the Under patch is inserted first.
Indicates the under patch is inserted first
1-10
Indicates the strip is inserted
into the 35mm slot
Indicates the strip type to measure
