Icom IC-9700 Advanced Manual page 100

9. D-STAR OPERATION (BASIC)
Updating the repeater list
Step 3: Copying the CSV file to the SD card
1. Double-click the "9700_USA_yymmdd" folder
created in the same place where the downloaded
file is saved.
2. Copy the CSV file (Example: "9700_USA_Rpt_
yymmdd. csv") in the folder and paste it in the
"RptList" folder ("IC-9700" > "Csv" > "RptList") of
the SD card.
Step 4: Removing the SD card
Turn OFF the transceiver, then remove the SD card
from your PC, and insert it into the transceiver's slot.
TIP: We recommends that you save the current
data before loading other data into the transceiver.
Transceiver
SD card
From the memory
card reader
Paste the copied
CSV file in this folder.
Step 5: Updating the repeater list
1. Open the IMPORT/EXPORT screen.
» SET > SD Card > Import/Export
MENU
2. Touch "Import."
3. Touch "Repeater List."
4. Touch the CSV file to be loaded.
(Example: 9700_USA_Rpt_yymmdd)
5. Touch [YES] or [NO].
• YES: Retains the skip settings of the repeater list.
(See page 10-25)
• NO: Does not retain the skip settings of the
repeater list.
6. Touch "YES."
• Starts the import.
• After importing ends, "COMPLETED!" is displayed.
7. To complete the importing, reboot the transceiver.
PC
TIP: If you copy the ICF file to the "Setting" folder
of the SD card, the repeater list can be updated
with the same procedures. In that case, select
"Load Setting" on the SD CARD screen. And on the
LOAD FILE screen, select "Repeater List Only."
» SET > SD Card > Load Setting
MENU
9-12
