SmartFusion2 SoC FPGA CoreTSE_AHB 1000 Base-T Loopback Demo
Table 1 •
Software Requirements
Libero SoC
FlashPro Programming Software
SoftConsole
Cat Karat Packet Generator Software
Wireshark Software
IP Requirements
CoreTSE_AHB
2.2

Demo Design

The demo design files are available for download at:
http://soc.microsemi.com/download/rsc/?f=m2s_dg0637_liberov11p8_df
The demo design files include:
• Libero project
• Programming files
• Source files
• Readme.txt file
See the Readme.txt file for the complete directory structure.
The following figure shows the top-level structure of the design files.
Figure 1 • Demo Design Files Top-Level Structure
Design Requirements (continued)
DG0637 Demo Guide Revision 3.0
11.8
11.8
v4.0
Provided with design files
Provided with design files
License provided on request. Send an
email to soc_marketing@microsemi.com.
3
