Demo Requirements

The following table lists the required hardware and software for running the demo.
Table 1 •
Hardware Requirements
SmartFusion2 Security Evaluation Kit:
• FlashPro4 programmer
• USB A to Mini - B USB cable
12 V Adapter
Operating System
Software Requirements
®
Libero system-on-chip (SoC) software v11.8 SP1
SoftConsole
FlashPro programming software
Host PC Drivers
For launching demo GUI
2.2.1

Design Files

The demo design files are available for download from the following path in the Microsemi website:
http://soc.microsemi.com/download/rsc/?f=m2s_dg0388_liberov11p8_sp1_df
Design files include:
• Libero
• Programming files
• GUI Executable
• Readme file
The following figure shows the top-level structure of the design files. For further details, see the
readme.txt file.
Figure 2 • Demo Design Top-Level Structure
<download_folder>
Demo Requirements
M2S90_eSRAM_EDAC_DF
GUI Executable
Libero
Programming File
readme.txt
DG0388 Demo Guide Revision 10.0
Description
Rev D or later
Any 64-bit or 32-bit Windows XP SP2
Any 64-bit or 32-bit Windows 7
v4.0
v11.8 SP1
USB to UART drivers
Microsoft.NET Framework 4 client
3
