SmartFusion2 SoC FPGA - Adaptive FIR Filter Demo
2.3

Design Requirements

Table 1 • Design Requirements
Design Requirements
Hardware Requirements
SmartFusion2 Starter Kit
• FlashPro4 programmer
• USB A to Mini-B cable
SmartFusion2 Security Evaluation Kit
• FlashPro4 programmer
• USB A to Mini-B cable
Host PC or Laptop
Software Requirements
®
Libero System-on-Chip (SoC)
SoftConsole
FlashPro Programming Software
Host PC Drivers
Framework
2.4

Demo Design

The design files are available for download from the following path in the Microsemi
• SmartFusion2 Starter Kit:
http://soc.microsemi.com/download/rsc/?f=m2s_dg0441_starter_liberov11p8_sp1_df
• SmartFusion2 Security Evaluation Kit:
http://soc.microsemi.com/download/rsc/?f=m2s_dg0441_eval_liberov11p8_sp1_df
Design files include:
• Design files
• Programming files
• GUI executable
• Readme file
The following figure shows the top-level structure of the SmartFusion2 Starter kit design files. For further
details, refer to the readme.txt file.
Figure 5 • SmartFusion2 Starter Kit Demo Design Files Top-Level Structure
The following figure shows the top-level structure of the SmartFusion2 Security Evaluation kit design
files. For further details, refer to the readme.txt file.
Description
SF2-484-STARTER-KIT (M2S010-FGG484)
Rev D or later (M2S090TS-FGG484)
Windows 7, 64-bit Operating System
v11.8 SP1
v 4.0
v11.8 SP1
USB to UART drivers
Microsoft.NET Framework 4 Client for launching demo GUI
<download_folder>
SF2_Starter_Adaptive_FIR_filter_Demo_DF
DesignFiles
GUI
Programming files
Readme.txt
DG0441 Demo Guide Revision 7.0
®
website:
5
