1.4

Order code

The MSD Single-Axis Servo Drive Compact has the article designation
G394-xxx-xxx-xxx. The provides information on the related variant of the supplied
MSD Servo Drive. The significance of the individual characters of the article designation
is given in the following order code.
You will find the complete order code with all values in the MSD Ordering Catalog.
G394 - -
Rated current
Option 1 (Communication)
Option 2 (Technology)
Option 3 (Safety)
Option 4 (Function package)
Modificatio
Variants
1.5
On rating plates for the MSD Single-Axis Servo Drive Compact you will find the serial
number, from which you can identify the date of manufacture based on the following
key. For the location of the rating plate on the servo drive refer to "Figure 4.1 Layout
MSD Single-Axis Servo Drive Compact C2 to C4" and "Figure 4.2 Layout MSD Single-
Axis Servo Drive Compact C5".
MOOG
-
D-71034 Böblingen
www .moog.com/industrial
Made in Germany
Fig. 1.1
1.6
The scope of supply includes:
y
y
y
y
MSD Single-Axis Servo Drive Compact Operation Manual

Production data

Model: : G394-030-210-001
S/N : D116605 Rev. A
In: 230 V AC 3ph, 50/60 Hz
4,0 A
Out: 0-230 V AC 3ph, 0-400 Hz
3,0 A
ID : JJWWxxxxx
MSD Single-Axis Servo Drive Compact hardware rating plate

Scope of supply

MSD Single-Axis Servo Drive Compact
Terminal kit for control and power terminals
(depending on device power and variant)
Set with shield connecting plates and fixing material
Product CD with booklet
6
Year of production
Week of production
