5.4.5

Ethernet IP address menu (IP)

An Ethernet TCP/IP port is available as a service and diagnostics interface. The IP
address is set by default to 192.168.39.5 and the subnet mask to 255.255.255.0. Both
can be changed using the IP address menu.
Menu level Pa-
Value
rame- Meaning
1 2 range
ter
IP
Iu b0 00..FF IP address
update byte 0
b1 00..FF IP address
update byte 1
b2 00..FF IP address
update byte 2
b3 00..FF IP address
update byte 3
Ir - - IP reset to
factory setting
Su b0 00..FF Subnet mask
update byte 0
b1 00..FF Subnet mask
update byte 1
b2 00..FF Subnet mask
update byte 2
b3 00..FF Subnet mask
update byte 3
Sr - - Subnet mask
reset to
factory setting
Table 5.10 IP address menu
moog
ID no.: CA97555-001 Date: 04/2018
Explanation
Setting for byte 0 of the IP address in hexadeci-
mal format
(e.g. "05" for 192.168.39.5)
Setting for byte 1 of the IP address in hexadeci-
mal format
(e.g. "27" for 192.168.39.5)
Setting for byte 2 of the IP address in hexadeci-
mal format
(e.g. "A8" for 192.168.39.5)
Setting for byte 3 of the IP address in hexadeci-
mal format
(e.g. "C0" at 192.168.39.5)
Reset IP address to factory setting
(192.168.39.5)
Setting for byte 0 of the subnet mask in hexadec-
imal format
(e.g. "00" at 255.255.255.0)
Setting for byte 1 of the subnet mask in hexadec-
imal format
(e.g. "FF" at 255.255.255.0)
Setting for byte 2 of the subnet mask in hexadec-
imal format
(e.g. "FF" at 255.255.255.0)
Setting for byte 3 of the subnet mask in hexadec-
imal format
(e.g. "FF" at 255.255.255.0)
Reset subnet mask to factory setting
(255.255.255.0)
Example configuration of the subnet mask
In this example the subnet mask is changed from 255.255.255.0 to 122.255.255.0.
NOTE:
Changes on the IP address menu are only applied when the control
electronics are subsequently restarted.
