Timer Menu Options

• SHORT DOOR TIMER (Range: 0.5-120.0 Seconds)
• Determines length of time doors will stay open after being reopened by Photo Eye,
Safety Edge, or Door Open button.
• CAR CALL DOOR TIMER (Range: 0.5-120.0 Seconds)
• Determines length of time doors will stay open when car stops to service a car call.
• HALL CALL DOOR TIMER (Range: 0.5-120.0 Seconds)
• Determines length of time doors will stay open when car stops to answer a hall call.
• LOBBY DOOR TIMER (Range: 0.5-120.0 Seconds)
• Length of time doors will stay open when car stops to answer either a hall call or a car
call at Lobby Floor. Location of Lobby Floor is programmable.
REAR/FLR 1? (simplex) / THIS CAR SERVES REAR/FLR 1? (duplex)" on page
• NUDGING TIMER (Range: 10-240 Seconds)
• Used only if the Nudging option is selected. Door Nudging Operation will begin when
Nudging Timer elapses. Nudging Timer will start when regular door timer elapses.
This timer also determines the ON and OFF cycle time for the NUDG output.
"NUDGING?" on page
• TIME OUT OF SERVICE TIMER (Range: 15-240 Seconds, or None)
• Used to take a car out of service when it is held at a floor excessively and calls are regis-
tered at other floors. Timer starts when a call is registered at another floor. If timer
expires before the car closes its doors and begins to move, the car will be placed out of
service. Typically, this occurs when doors are held open by continuous activation of
photo eye, a call button, or another reopening device. When NONE is selected, no
Time Out of Service timing is performed.
When the timer expires, the Timed Out of Service Indicator on the HC-MPU board will
turn ON. The controller will ignore the PHE (Photo Eye) input if the Stuck Photo Eye
Protection option is selected. In duplex or group installations, hall calls assigned to the
car will be assigned to another car. When the car closes its doors and begins to move
again, it will return to Normal service.
• MOTOR LIMIT TIMER (Range: 1.0 - 6.0 Minutes)
• Timer starts when the controller attempts to move the car and is reset when the car
reaches its destination floor. If the timer expires before the car reaches its destination,
the controller stops trying to move the car to protect the motor. The car is then shut
down. The Motor Limit Timer Indicator (MLT) on the HC-MPU board will turn ON.
• MGR OUTPUT TIMER (Range: 1.0 - 27.0 Minutes)
• Timer starts when car is idle at floor. When timer elapses, the motor/generator is shut
down. Upon demand, the motor/generator will be restarted and brought up to readi-
ness before the car can move.
