Motion Control Engineering Motion 4000 Manual page 431

Motion 4000
Table A.3 F7 Parameter Log
ID#
Slew Filter: Smooths any harsh transitions in
144 the commanded speed. Reducing this value
causes a smoother transition.
Contract Overspeed: Setting in feet per min-
145 ute above contract speed at which a contract
overspeed is detected.
Inspection Overspeed: Setting in feet per min-
ute above inspection speed at which an
146
inspection overspeed is detected and an emer-
gency stop initiated.
Leveling Overspeed: Setting in feet per minute
above leveling speed at which a leveling over-
147
speed is detected and an emergency stop initi-
ated.
Hoist-motor Speed: Setting in drive sheave
148
RPM at which the car achieves contract speed.
Contract Speed: Contract speed of the car in
149
feet per minute.
High Speed: High speed limit for the Standard
150
curve. Usually the same as Contract Speed.
151 Intermediate Speed
152 Earthquake Speed
153 Auxiliary Speed
154 Backup power speed
155 Inspection Speed (Normal)
156 Inspection Speed (Reduced)
157 Correction Speed
158 Leveling Speed
159 Releveling Speed
160 Leveling Distance
161 Releveling distance
162 Proximity distance
165 Standard Start Jerk
166 Standard Roll Jerk
167 Standard Stop Jerk
168 Standard Acceleration
169 Standard Deceleration
170 Manual Start Jerk
171 Manual Roll Jerk
172 Manual Stop Jerk
173 Manual Acceleration
174 Manual Deceleration
Description
F7 Settings Record
Setting
A
A-19
