User Interface
Caution
Settings that affect the number of floors in the building, openings served per floor, discrete
or serial (CE) position indicators, or the presence or absence of a serial car call board deter-
mine the sequence of connections on Universal I/O boards used as "call boards" in the con-
troller (UIO boards with addresses from 0 to 31). These settings are made at the factory and
should never need to be changed. If you do need to change these settings, disconnect the
orange I/O terminal blocks from the UIO boards first, change the settings, then re-wire and
re-connect the terminal blocks.
• TOP LANDING SERVED? (simplex)/TOP LANDING FOR THIS CAR? (duplex)
• Set to the highest floor served by this car. See caution above.
• HC-RDR BOARD ON THIS CAR?
• Set to Yes if this car has a second set of doors controlled by an HC-RDR board.
• CAR SERVES FRNT/FLR 1? (simplex)/THIS CAR SERVES FRNT/FLR 1?
(duplex)
• Set to YES if this car is eligible to serve a front opening at this floor. (This prompt will
reappear for each floor.) See caution above.
• Press the '+' button to scroll through available landings. Press N for the next option.
• CAR SERVES REAR/FLR 1? (simplex) / THIS CAR SERVES REAR/FLR 1?
(duplex)
• Set to YES if this car is eligible to serve a rear opening at this floor. (This option will not
be displayed if option CARS ARE WALK-THRU? is set to NO.) (This prompt will reap-
pear for each floor.) See caution above.
• Press the '+' button to scroll through available landings. Press N for the next option.
• For a duplex, option inquiries for CARS ARE WALK-THRU?, CAR SERVES FRNT/
FLR 1? and CAR SERVES REAR/FLR 1? must be answered for both cars. Each mes-
sage will ask what the other car's top landing is, if it serves rear floors, etc. Again, select
YES if the other car of the duplex serves that floor and NO if the other car does not.
Both controllers in a duplex need to be programmed with this information.
• TOP LANDING FOR OTHER CAR? (duplex)
• Set to the highest floor served by the other car of the duplex pair.
• HC-RDR BOARD ON THE OTHER CAR? (duplex)
• Set to Yes if the other car of the duplex pair has a second set of doors controlled by an
HC-RDR board.
• PARKING FLOOR
• Any landing may be the parking floor. The car will go to the parking floor when it is
free of call demand. There is a Parking Delay Timer that will cause a free car to wait for
a short time before parking. The timer is adjustable, with a value between 0.0 minutes
(no delay) and 6.0 minutes
on page
• If the parking feature is not needed, choose NONE. The car will then stay at the last
call answered.
4-14 Manual # 42-02-2P24
(see "PARKING DELAY TIMER (Range: 0.0-6.0 Minutes)"
4-24).
