User Interface
F5 Menus
The F5 switch provides access the three menus:
• Controller Utilities Menu
• A way to register front and rear car calls from the controller or the hand-held device
• Allows you to view and set date and time for controller time stamping
• View and/or clear the event log
• Default TC-MPI parameters
• Displays position/speed related diagnostics (TC-MPI Diagnostics)
• View inputs and outputs of system control panel serial interface boards
• Monitoring & Reporting
• Set up and view Ethernet communications for monitoring applications
• Terminal Limit Utilities Menu
• Learn limit switch positions
• FCL Brake Unit Utilities Menu
• FCL Diagnostic Menu
• FCL Power Data Menu
• Default TC-FCL Parameters
• FCL Adjustment Menu
To view:
F5 up (all others down). Press N to advance through menus. Press S to select a menu.
4-62 Manual # 42-02-2P24
