Motion Control Engineering Motion 4000 Manual page 257

Motion 4000
Table 4.13 MPI-B Diagnostics
Address
Port A outputs:
01 = (n/a)
02 = (n/a)
03 = DIA2B
04 = DIA1B
05 = DIA7B
06 = DIA7B
07 = (n/a)
110 08 = (n/a)
09 = (n/a)
10 = DIA6B
11 = DIA5B
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = DIA8B
16 = DIA8B
111 Port B outputs: (n/a)
Port C outputs:
01 = (n/a)
02 = (n/a)
03 = (n/a)
04 = (n/a)
05 = (n/a)
06 = (n/a)
07 = (n/a)
112 08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = SPB ON LED
Port D outputs:
01 = (n/a)
02 = (n/a)
03 = PME
04 = BRE
05 = DRE
06 = EB2
07 = EB3
113 08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
114 Port E outputs: (n/a)
115 Port F outputs: (n/a)
Item
F5 Menus
Notes
4
4-79
