Motion 4000

Operating Mode Descriptions

Available operating modes are configured when the car is installed. Not all modes are available
on all cars. This section describes operating modes, including:

• Normal Operation

• Inspection Operation

• Attendant Operation
• Independent Operation
• Sabbath Operation
• Emergency Medical Operation
• Hospital Operation
• Seismic Operation
• Fire Operation
• Emergency Power Operation
• Car Recall
• Capture for Test
• Test Mode
Normal Operation
Normal operation is the default elevator operating mode. In this mode, cars are accepting hall
calls and servicing car calls as determined by Basic Features Menu and other operating menu
selections.
speed as affected by short or multi-floor run performance curves.
Inspection Operation
In inspection, a car operates at the set inspection speed using continuous pressure up and down
buttons or switches. The car will stop as soon as the buttons are released. Inspection operation
may be controlled from four locations. For safety purposes, locations have a priority:
• Cartop
• In-Car
• Access
• Machine Room Inspection

Cartop Inspection

In this mode, the car is operated by pushing the cartop UP or DOWN and ENABLE buttons
simultaneously. These buttons are generally provided through a third-party inspection station
wired to inspection operation inputs in the elevator controller. There will also be a key switch
that enables/disables inspection operation.

Mode Entry

• Bring the car to the access floor
• Enable hoistway access operation using the in-car switch
• Move the car down using the hall controls until the access limit is opened
• Set the cartop switch to Inspection and access the cartop.
• Use ENABLE and UP or DOWN buttons to run the car from the cartop.
(cartop, in-car, access, machine room)
Please refer to "Basic Features Menu" on page
Operating Mode Descriptions
4-13. Cars are running at contract
